Audley ADL07K12 Shaker
Built with efficiency and safety in mind, the ADL07K12 features automatic powder feeding, a built-in multi-stage air purifier, and an advanced PLC control system for simple, stable operation. Its compact design at just 1611mm in length fits through standard doorways, making it an ideal all-in-one solution for professional DTF businesses.
Package Size
161*94*94cm(Machine) 170*109*111cm(Crated)
Weight
242KG
Product Overview
The ADL07K12 powder shaker is designed to pair seamlessly with Audley 2H DTF printers, supporting film widths up to 600mm and speeds up to 27m/min. Featuring 6 lamp tube heating units at 300W each and a two-stage adjustable drying system, it ensures consistent and reliable powder curing for your DTF production.
Technical Specifications
| Shaker Model | ADL07K12 | ||
| Applicable Film Width | ≤ 600mm | Applicable Speed | ≤ 27m/min |
| Drying Method | Lamp tube heating | Number of Heating Lamps | 6 lamps × 300W |
| Recommended Drying Temp | 90–120°C | Platform Heating Temp | 75°C |
| Media Type | PET transfer film | Media Transport | Mesh belt conveyor with take-up unit |
| Power | 2900W | Voltage | AC 220V, 50–60Hz |
| Working Environment | Temperature: 18°C–30°C / Humidity: 40%–60% | Packing Size | 170*109*111cm |
| Machine: 161*94*95cm | |||
| Weight | 242KG (incl. built-in purifier) | Warranty | 1 year |
System Requirements
| CPU | Intel Core i7-9700K or above, or equivalent AMD |
| Memory | 8GB or above |
| Motherboard | Z370 or equivalent (compatible with CPU) |
| Storage | 128GB SSD + 1TB HDD |
| OS | Win7-64bit / Win10-64bit / Win11-64bit |
| Network | Gigabit Ethernet (Gigabit/GBE/10/100/1000M) |
| USB | Onboard USB 2.0 + USB 3.0/3.2 |
Equipment Details
